NOTICE
Clean the Spray Gun IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Spray Gun.
D=H6BC QR6S=B?Q> @=?>B6>=>;6D6BTR
H"3'(*%=-%%R&($,+7*%="(%D'//7E%D*$'/
C
E F
B
D
A*#4("/$"&8 H'84$"&8
A Air Hose Connects air to tool
B Filter Prevents dirt and condensation from damaging tool or workpiece
D Regulator Adjusts air pressure to tool
E Coupler and Plug Provides quick connection and release
C Air Cleaner / Dryerf Prevents water vapor from damaging workpiece
F Air Adjusting Valvef For fine tuning airflow at tool
fQ/$"&8,7%4&5/&8*8$#1
