Z059 User and Installation Guide January 2010
Page 3
Specifications
CAN Only CAN / ISO
Protocol s
Supported
ISO 15765-4 CAN 11 / 29 bit ISO 9141-2
ISO 14230-4 KWP
ISO 15765-4 CAN – 11 / 29 bit
Vehicle
Connectors
OBD 16 pin fully populated with locking tab
Ignition Detect Wire* 12 volts nominal = Z059 active
Meter
Connections
WHITE VSS Signal 0 - 5V - 5mA max.
Current
Consumption
15 mA 50 mA
VSS
Frequency
14400 pulses / Km 23175 pulses / mile
CAN Only model
Installation
● Wire the taximeter to the Z059 according to the diagram below. Note which model
you have.
Model VSS Output
Wire
Ignition Detect
Wire
Description
1.05 White None Standard Z059
1.08 White Green Standby Mode from ingition
Note that installation of the ignition wire is optional. It is recommended to minimize
drain on the vehicle’s battery with the engine off. Some vehicles may exhibit excessive
battery drain and require this feature.
