Screen, Symbols
SYMBOLS
Technical instructions REGULATION Cm Pelet-set
Winter working mode
(only heating)
External control ( / )
Summer working mode
(only DHW)
View/additional equipment button
(All items of additional equipment
are enabled)
Some items of the additional
equipment are disabled
All items of additional equipment
are disabled
Accumulation tank with current
temperature at top of the tank and
at the bottom of the tank.
Hydraulic crossover with the
current temperature
(there are configuration without
temp. sensor)
Domestic hot water tank
with current temperature
Heating circuit
Room thermostat
Next to the room thermostat
symbol bright blue circle (the
room thermostat has requested
for operating the pump, the pump
does not work if you have not met
all the conditions for its operation,
for example. low temp. in the
boiler, otherwise normally works)
Cm WiFi-box - not connected
Cascade
Cm WiFi-box - connected
Winter working mode
(heating + DHW)
