7
ForcedLearn
Maybeinitiatedbylongpressof;
LearnButton(Fig.6‐Aor7‐A)for3sec,or
Button4ofaMassLearnedtransmitter
– Light willpausedsingleblinkonceOpenerhasentered
ForcedLearnMode
Repeatedlycycletheopener
– Light
willextinguishoncelearningiscomplete
AutomaticRelearn
AnAutomaticReLearnwillbeinitiatedimmediately
subsequenttoeitheroneofthefollowing3occurrences;
– Runtimedeviationbecomingexcessive,or
– SafetyReverseoccurringon3consecutiveoccasions,or
– SafetyStopoccurringon3consecutiveoccasions.
DuringrelearnLED
(Fig.7‐I)willpausedsingleblinkthen
extinguishoncerelearniscomplete
MMODE
Description
AlesssensitiveSafetyReversesystemmoresuitedforuse
suitedforuseonlarge,hea vyorbadlyworndoors.
Function
Featuresconventionalonetimeforceadjustment–duringa
closingmovementtheOpenerwillstopandcommenceto
SafetyReverseuponencounteringanobstruction.
Enabling
Switchpoweroff
atpoweroutlet
Removethelightcover
SelectDip1(Fig.7‐G)tothe“OFF”position
Adjustment
LongPressLearnButton(Fig.7‐A)‐Light(Fig.7‐I)paused2x
blink–forceadjustmentcanonlybecarriedoutwhilethe
Lightisblinking
OpenDirection‐turn
theGreen“Open”adjustpin(Fig.7‐C)
toadjustopendirectionSafetyStopvalue–clockwiseto
increaseforce,anti‐clockwisetodecreaseforce
CloseDirection‐turntheRed“Close”adjustpin(Fig.7‐D)
toadjustclosedirectionSafetyReversevalue–clockwiseto
increaseforceandanti‐clockwiseto
decreaseforce
Momentarilypress“Learn”Buttontocloseoutthe
adjustmentmode
TestingCloseDirectionForce
Ensurethatthegaragedoorisrestingfirmlyagainstthe
ground.
Openthedoorandplacea40mmthickblockofwoodon
thegroundunderthepathofthedoor.
Initiateaclosemovementviatransmitterorrunbutton–if
thedriveforcevalueiscorrecttheopenerwillstopand
reversedirectionuponencounteringtheblockofwood.
Iftoolittleortoomuchforceisrequiredtomakethe
openerreversedirection–turntheRed
OffsetAdjustPin
(Fig.7‐D)5degreesintheappropriat edirection–towards
Maxtoincreaseforce–towardsMINtodecreasethe
amountofforce–andthenrepeatthetest.
TestingOpenDirectionForce
Duringanopenmovementapplysomefirmdownward
forcetothegaragedoor.
IftheSafetyStopvalueiscorrecttheOpenerwillstopupon
sensingtheresistance.
Iftoolittleortoomuchforceisrequiredtomakethe
openerstopturntheGreen“Offset”AdjustPin(Fig.7‐C)5
degreesintheappropriatedirection–towards“MAX”to
increaseforce
–towards“MIN”todecreasetheamountof
force–andthenrepeatthetest
Function
AutoCloseautomaticallyclosesthedoor;either5secaftera
carhaspassedthroughthedoorwayorafter30secifacar
hasnotpassedthroughthedoorway.
ToEnable
SelectDips2and3(Fig.7‐G)tothe“ON”position.
– Note‐AutoClosewillonlyfunctionwhenSafetyBeams
havebeenfittedandenabled
Function
TheCourtesyLight;
– providesgarageilluminationandopenerstatusindication
– willilluminateautomaticallyeachtimetheOpeneris
activatedandwillswitchoff90secafterthelast
activation
– maybeswitchedonandoffviabutton3ofabulklearned
transmitter(refersec.10)
Indication
– Slowblink
–LearningForcevalues
– 2xblinkwhentransmitterispressed–SafetyBeam
malfunction
– 3xblinkduringForcelearning–doorloadisexcessive
– 4xblinkwhentransmitterispressed–Openerhas
enteredVacationMode
ON OFFONOFF
Dip1 AutoForceMode ManualForceMode
Dip2 SafetyBeamsEnabled SafetyBeamsDisabled
Dip3 AutoCloseEnabled AutoCloseDisabled
Dip4 DoorServiceEnabled DoorServiceDisabled
Dip5 MassLearning SimpleLearning
Dip6 LeftHandInstallation RightHandInstallation
Dip7Doorsover2.5mhigh Doorsupto2.5mhigh
16.DipSwitches
14.
