• Code 128
• Codabar
• Interleaved 2 of 5
• Industrial 2 of 5
• Matrix 2 of 5
• UPC-A/UPC-E
• EAN-8/EAN-13
• EAN/UCC 128
• China Postal Code
• MSI Plessy Code
• UK Plessy Code
• IATA Code
• Telepen Code
Resolution 6 mils (PCC – 90%)
Print contrast ration > 60%
Bars must be centered 11mm from the edge of the card and should
be 10mm high or more. There must be at least 6mm white space on
both sides of the bar code.
6.15 Terminal Block
Optional relay output and digital input.
Two Form C relay outputs; 1A at 30V DC
Two Optically Isolated Inputs; 24V DC, 1.2Kohm
6.16 Certifications
CE Mark, FCC Part 15 Class A
