CERONIX 15, 17, 19,
20, 22 INCH LCD MONITOR SPECIFICATIO
N AND SERVICE MANUAL
13
8. Mechanical & Envi
ronmental Specifications
Dimensions (W x H x D)
19.815” x 13.020” x 2.806” (2200X-LCD)
Environment
Operational 0° to 70°C, Humidity 5% to 90% Non-Condensin
g
12
14
Table of Contents
Table of Contents
4
General Description
5
General Features
5
Electrical and Panel Specifications
6
Application Timing
7
Mechanical and Environmental Specifications P9-13
9
Mechanical Rendering
14
OSD Navigation
15
Burn-In Mode P20
20
A/D Controller Board P21
21
A/D Controller Board Pin Description P22-27
22
