CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 21
12. A/D Controller Board
Ceronix Part Number CPM2376
CONNECTOR DESCRIPTION
CN1 TOUCH POWER
CN3 DC INPUT
CN4 OSD KEY PAD
PIN COUNT
3
2
10
CN5 INVERTER CONTROL 5
CN6 IR BOARD 6
CN8 LCD LVDS 32
CN11 VGA ANALOG INPUT 15
CN9 DVI INPUT 24
