CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 5
4. General Description
This specification and operation manual defines the characteristics and
performance of the Ceronix 15, 17, 19, 20, 22 Inch LCD Monitors. This product
is capable of displaying resolutions from VGA to SXGA. The built in A/D
controller is capable of displaying up to 16,777,216 colors based on its red,
green, and blue analog video input. Video synchronization signals of applicable
resolution modes can be automatically detected in the range of 15.5kHz to 80kHz
horizontal and 56Hz to 75Hz vertical. Unless otherwise specified, the product
shall meet the specifications described in this document.
5. General Features
Native Resolution:15”(1024X768 Pixels),17”, 19” (1280X1024), 20” (1600X900),
22” (1680X1050)
Color: 16,777,216 (8 Bit Color)
Input:
1. 15-Pin H-Dsub Analog RGB (0.7Vp-p, 75ohm, H/V Sync, TTL)
Horizontal Frequency Range: 31.5kHz~80kHz
Vertical Frequency Range: 56~75Hz
2. 24-Pin DVI-D
Controls:
1. OSD navigated keypad with Menu, Up, Down, Select, and Power.
2. Optional Infra-red remote control.
OSD Menu:
Contrast Brightness, Color Adjust, H-Position, H-Size, V-Position, Language,
Reset, Signal Source.
Mechanical Flexibility:
Monitor Chassis designed to fit into numerous applications with existing
mounting studs or with adapter brackets.
Optional Touch Sensor allows for interactive display.
Infra-Red remote allows for easy adjustment.
All electrical components designed for long life and running in industrial and
gaming applications
