PILOT'S OPERATING
HANDBOOK
SUPPLEMEIVT
14
CESSNA
2OOA
AUTOPILOT
(TYPE AF-29õB)
INFLIGHT WINGS
LEVELING:
1. Airplane Rudder Trim
--
ADJUST
for
zero slip
("Ball"
centered
on
Turn Coordinator).
2. PULL-TURN Knob
--
CENTER,
and PULL
out.
3. A/P
ON-OFF
Swiùch
--.ON.
4. Autopilot
TRIM Control
-- ADJUST
for
zero
turn
rate
(wings
level
indication on
lurn Coordinator).
NOTE
and
1U206
Series Modele.
COMM.ÀND TURNS:
1.
PULL-TITRN Knob --
CENTER,
PULL out and
ROTATE.
DIR,ECTION
HOLD:
1.
PULL-TIIRN
Knob
--
CENTER,
and PIILL out.
2.
Autopilot TRIM
Control
-r
ADJUST for
zero
tum rate.
3. Airplane
Rudder Trim
--
ADJUST for zero
slip
("Ball"
oentered).
4. DIR
HOLD
Button
--
PUSH.
õ.
PULL-TITRN
Knob
--
PUSH
in detent
positiotr
whetr
airplane
ís
on
desired
beading.
6. Autopilot
TRIM
Control
--
READJUST
for
zero
tu¡a
ra,te.
NAV
CAPTURE
(VOR/LOC):
1.
PUIJL-TITRN
K¡ob --
CENTER, and
PIILL out.
2. NAV
1-Z
Selector
Switch
--
SELE¡CT
desired
VOR
receiver.
3.
Nav Reoeiver
OBS or ARC Knob
--
SET
desired
VOR,
oourse
(if
tracking
onni).
NOTE
Optionat
ARC
knob
should
be
iD
centerposition
andARC
ember
waming
light
should be off.
4.
N.A'V
CAPT
Button
--
PUSH.
õ. HI
SENS Buttou -- PUSH for
localizer
aud
"close-in"
omni
inter-
cepts.
õ
80
May 1980
