OIL
DILUTION
TABLE
TEMPERATURE
0
0
F.
-10
0
F.
-20
0
F.
DILUTION
TIME
====
30seconds
1
minute
1
minute
30
seconds
FUEL
ADDED
1
quart
2
quarts
3
quarts
Maximum
sump
capacity
for
take-off,
10
quarts.
Figure
7-1.
If
the full dilution
time
was
used,
beginning with a full oil
sump
(10
quarts),
subsequent
starts
and engine
warm-up
should be
prolonged
to
evaporate
enough of the fuel to
lower
the
oil
sump
level
to
10
quarts
prior
to
take-off.
Otherwise,
the
sumps
may
overflow when the
airplane
is
in
a
nose
high
attitude.
To
avoid
progressive
dilution of the oil,
flights
of
at
least
two
hours
I
duration
should
be
made
between
dilution
operations.
STATIC
PRESSURE
ALTERNATE
SOURCE
VALVE.
A
control
knob
to
the
left
side
of
the
control
pedestal,
under
the
in-
strument
panel,
operates
the
static
pressure
alternate
source
valve.
The
valve
provides
continued
operation
of the
airspeed,
altimeter
and
vertical
speed
indicators
in
the
event
that
the
static
system
ports
or
lines
become
obstructed.
If
erroneous
instrument
readings
are
suspected,
due to
water
or
ice
in
the
static
system
ports
or
lines,
the
static
pressure
alternate
t
~,
"
I
>
~
.
_
source
valve
should be opened by pulling out
the
control
knob, thus
vent-
ing the
static
system
into
the
left
wing.
A
placard
on
the
left
side
of the
control
pedestal
lists
the
following
corrections
to be used for indicated
airspeed
and
altitude
when
the
alter-
nate
static
source
must
be
used.
ALTERNATE STATIC SOURCE CORRECTION
AIRSPEED
FLY 3 MPH FASTER THAN NORMAL.
ALTITUDE
CRUISE: FLY 270
FEET
HIGHER THAN NORMAL.
APPROACH: FLY 100
FEET
HIGHER THAN NORMAL.
;
II
;
ICE
DETECTOR
LIGHT I
An
ice
detector
light
may
be
installed
to
facilitate
the
detection
of
wing
ice
at
night
or
during
reduced
visibility.
The
ice
detector
light
system
consists
of a
split
rocker-type
switch
labeled
"WING DEICE
LITE"
located
on the
left
switch
and
control
panel,
and a
light
positioned on the upper
left
side
of
the
fuselage
forward
of
the
wing to
illuminate
the
leading
edge of
the
wing. To
operate
the light,
place
the
right
half of the
split
rocker-type
switch
(single
rocker
without
de-ice
system)
in the up (on)
position.
'-5
J
7-4
