MAINTENANCE & LUBRICATION
149
Head light replacement
1. Access the head light bulb:
• Remove the screw
1
, and plastic clamps
2
from the
inner fender panel.
• Remove the panel
3
to expose the head light housing.
2. Turn the bulb access cover
5
60 degrees anti-clockwise
and remove it from the housing.
3. Turn the lamp holder
6
60 degrees anti-clockwise and
remove the lamp holder from the head light housing.
4. Remove the failed bulb and replace it with a new bulb.
5. Reinstall the lamp holder into the headlight housing.
6. Test the bulb and ensure it is working properly.
7. Bulb Specification (head light):
HS1 35W×2
CAUTION
Hot surface. Touch the bulb only after it has cooled down.
