FEATURES AND CONTROLS
Foot Controls
Foot Brake -
12
The foot brake pedal is located on the right side oor board of the
vehicle. Push down on the pedal to apply both the front and rear
brakes. When pressed, the pedal should feel firm. A soft brake
pedal would indicate a possible fluid leak or low master cylinder
fluid level, which must be corrected before riding. Contact your
dealer for proper diagnosis and repairs.
Foot Brake Fluid Reservoir and Level Indicator -
13
Check the foot brake master cylinder fluid level before each use
of the ATV. The foot brake master cylinder is located under the
front access cover. The uid level can be viewed on the side of the
master cylinder. If the uid level is lower than the “lower” mark, rell
with brake uid as necessary. The foot brake uid reservoir is near
the right foot rest under the front access panel.
WARNING
An over-full master cylinder may cause brake drag or brake lock-
up, which could result in serious injury or death. Maintain brake
uid at the recommended level. Do not overll.
12
13
