CF COMFORT - Table of Contents; Safety Warnings

3
UTILISATION
3
INSTALLATION
SAFETY INSTRUCTIONS........................................................................................................p. 3
USE ..................................................................................................................................... p. 4-7
Electric box test ...............................................................................................................p. 4
Setting the timer .............................................................................................................. p. 6
Setting the motor circuit breaker ...................................................................................p. 7
SERVICING ............................................................................................................................p. 8
INFORMATION .......................................................................................................................p. 9
FAQs .................................................................................................................................. p. 9
SPARE PARTS ....................................................................................................................... p. 10
WARRANTY ..........................................................................................................................p. 11
PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP THEM FOR FUTURE REFERENCE
The aim of this CF control boxes instruction manual is to provide you with all the
information you need for optimal installation, use and maintenance. It is essential to
read this document carefully and to keep it in a safe place for future reference.
Wear proper safety equipment (safety shoes, goggles, mask, gloves, appropriate
clothing) when installing the equipment!
Consult the instructions provided by the manufacturer(s) for power tools and products
used.
CONTENTS
2
SAFETY INSTRUCTIONS
SAFETY WARNINGS:
Prior to any wiring operation, a current protective device of 30mA maximum must be put
in place prior to installation of the pool and there must be connected earth-grounding
of a value lower than the regulatory threshold (usually <100 Ω, we recommend lowering
this threshold to 50Ω).
Electrical connections must be installed by a qualified electrician with BR certification.
Electrical installation norm applicable: for France, NF norm C 15-100, specifically article
702 and Guide UTE C15-559 for the lighting circuit.
Protective measure for people:
• Against direct contact from the casing
• Against indirect contact from use of the protection circuit.
Prior to any operation, switch o and lock the mains power supply!
Prior to any wiring operation: check and, if required, tighten the screws of the
appliances!
Rated voltage for use (control) Ue = 230V
Level of protection IP55
Neutral point connection TT
Frequency 50 Hz
Pump rated current I = 10A
Booster pump rated current I = 6A
Control + 2 LEDs rated current I = 4A
Control + 1x300W bulb rated current I = 6A
