CGS Instruments SAM-3000 - SAM-3000 Gas Flow Schematic; Exemplary Gas Flow Path

55/79
E
Product:
SAM-3000 / SAM-1950
Revision 1.0– Issue September 2015
5.4 Gas flow schematic
A exemplary gas diagram is shown below:
25-250 l/h 25-250 l/h
6-60 l/h
25-250 l/h
SAM-3000
sample gas 1
25-250 l/h
to analyser
ATM
example
sample gas 2
sample gas 3
sample gas 4
zero gas
span gas
