CGS Instruments SAM-3000 User Manual

65/79
E
Product:
SAM-3000 / SAM-1950
Revision 1.0– Issue September 2015
7 Technical data
Inlets Quantity
Inlet filter fineness
Diameter (outer)
1 ... 6
without, 20 μm or 50 μm
2, 3, 6 mm or 1/8“, 1/4“
Solenoid valves Standard
Option 1
Option 2
2/2-ways normally closed
2/2- ways normally open
3/2-ways
Bypass
flow meters
Quantity
Flow rate
1 ... 4
variabel 5-1200 l/h
Flow alarm Quantity
Flow rate
1 ... 4
variabel 5 - 1200 l/h
Flow
limitation
Standard
Option
Needle valve
Flow Controller 0 .. 96 l/h
Pressure
transmitter
Measuring range (Standard)
Output signal (Standard)
0 ... 1 bar
4 ... 20 mA
Materials All-wetted parts
Hounsing
Stainless steel 1.4571 PTFE
Aluminium, anodised
Interfaces DCS
Optional
Analyzer
bit parallel SUB-D37-pin
PROFIBUS DPV2
SUB-D9-pin
Dimensions SAM-3000
SAM-1950
483 x 4HU x 270 mm
241,5 x 5HU x 270 mm
Weight By complete expansion stage circa. 7 kg
Electrical
connections
Power supply
Fuse
24 V DC
M 1,6 A
