CGS Instruments SAM-3000 - Default Chapter; Table of Contents

42/79
E
Product:
SAM-3000 /SAM-1950
Revision 1.0 – Issue September 2015
Table of contents
Table of contents ....................................................................33
1 General information ................................................................35
1.1 Device version and validity .....................................................35
1.2 Information for our customers ..................................................35
1.3 General ....................................................................35
1.4 Warnings and explanatory texts .................................................35
1.5 Intended use ................................................................36
1.6 Qualified personnel ...........................................................36
1.7 Warranty information .........................................................36
1.8 Delivery information ..........................................................37
1.9 Norms and regulations ........................................................37
1.10 Disclaimer .................................................................38
2 Warnings and safety instructions ......................................................39
3 Packaging and transport ............................................................40
3.1 Packaging material ...........................................................40
3.2 Shipping labels ..............................................................40
3.3 Transport inspection ..........................................................41
3.4 Storage ....................................................................41
4 Installation, assembly information ....................................................42
5 Setup and function .................................................................43
5.1 Functional description .........................................................43
5.2 Design and operating mode ....................................................44
5.3 Dimensional drawing .........................................................45
5.4 Gas flow schematic ...........................................................46
5.5 Control PCB .................................................................47
5.5.1 Design and operating mode of the control PCB ...............................47
5.5.2 PROFIBUS DPV2 (Optional) ................................................51
5.6. Design and functions of solenoid valve manifold ...................................51
6 Technical data .....................................................................53
7 Maintenance & repair ...............................................................54
7.1 Replacing the solenoid valves / replacing the filter ..................................54
8 Device configuration (order code) .....................................................55
9 Spare parts .......................................................................56
10 Declaration of conformity ...........................................................57
11 Labelling-CD .....................................................................58
12 Cleaning ........................................................................59
12.1 Cleaning the surface .........................................................59
12.2 Cleaning the interior .........................................................59
12.3 Cleaning the control panel ....................................................59
