CGS Instruments SAM-3000 - Spare Parts List

71/79
E
Product:
SAM-3000 / SAM-1950
Revision 1.0– Issue September 2015
12 Spare parts
Pos
*PU Article
Order No.
1 1 pcs. Control and display board 1017998 (V1.0)
2 1 pcs. Control and display board with button 1018004 (V2.0)
3 1 pcs. Flow controller; 18 l/h; 1/8“; Alu-body; SS-diaphragm 1011221
4 1 pcs. Flow controller; 96 l/h; 1/8“; Alu-body; SS-diaphragm 1011223
5 1 pcs. Flow controller; 96l/h; 1/8“; SS-body; SS-diaphragm 1011224
6 1 pcs.
Pressure Regulator with pressure gauge; Inlet: 20 bar; Outlet: 0.5 - 3
bar; NPT 1/4“ female; Chrome-plated brass; with Panel-Mounting-
Ring for SL 20-P
1021835
7 1 pcs.
Flowmeter without valve; 10...100 Nl/h; without limit switch; nickel
plated brass; 1/4“ NPT; Air
1028362
8 1 pcs. Ring sensor; inductive; NAMUR bistable; 10 mm 1014583
9 1 pcs.
Pressure transmitter S-10; 0-25 bar; for general applications; stan-
dard version
1019509
10 1 pcs.
Solenoid valve; 2-ways; 24 VDC; D= 1.25mm; FKM; with connection
cable 700mm
1027695
11 1 pcs.
Solenoid valve; 3/2-ways; 24 VDC; D=1.25mm; with connection
cable 300mm
1019762
12 1 pcs.
Solenoid valve; O2; 2-way; 24 VDC; FKM; with connection
cable 700 mm
1030682
13 1 pcs.
Solenoid valve; O2; 2-way; 24 VDC; FKM; with connection
cable 700 mm
1030686
14 1 pcs.
Solenoid valve; O2; 3/2-ways; 24 VDC; with connection
cable 300 mm
1030684
15 1 pcs.
Solenoid valve; H2O; O2; 3/2-way; 24 VDC; with connection
cable 300 mm
1030688
16 1 pcs.
Solenoid valve; H2O; 2-ways; 24 VDC; D=1.25mm; with connection
cable 700mm
1024306
17 1 pcs.
Solenoid valve; 3/2-ways; 24 VDC; D=1.25mm; with connection
cable 300mm
1024308
18 1 pcs.
SS Integral Bonnet Needle Valve;Cv = 0.09; 3 mm Swagelok Tube
Fitting; PCTFE Stem Tip
1021802
19 1 pcs.
Flowmeter with needle valve; 25...250 Nl/h; without limit switch;
nickel plated brass; 1/4“ NPT; Air
1027287
20 1 pcs.
Pressure regulator GO; back pressure regulator; outlet: 3.5 bar; 50
PSI; 3 x 1/4“ NPT
1019170
21 1 pcs.
Flowmeter with needle valve; 15...150 Nl/h; without limit switch;
nickel plated brass; 1/4“ NPT; Luft
1021111
22 1 pcs. O-ring set (10 pcs); FKM 6.00x2.00mm 1026311
23 1 pcs. Sintered metal frit set (10 pcs); D=6.35mm; pore size 50μ 1026309
24 1 pcs. Quick coupling plug; RBE 03; internal thread M8x1 1015026
25 1 pcs. Quick coupling plug; RBE 03; internal thread G 1/8 1015027
26 1 pcs. Tube fitting set 1/16“ SS 1027699
