Chaffoteaux & Maury Mira System CF User Manual

10
Fitting the casing
Remove the protective film on the casing:
- offer up the casing (fig. 14)
- engage hooks N in notches R
operation 1
- fit the top of the panel in place
- screw in the 2 front panel securing screws A
Note: it is essential to refit both locking bolts A
Fig.15
A
8. Fitting the casing
1
N
R
R
N
Fig.14
