• Turn on the Foot A and Food B to the appropriate location (Fig.2) ,then upside down the machine.
• Mount the wheel in the same order illustrated in g 5 ensure the nut is not too tight.
• Lift up the button, push the collection box track to the appropriate location (Fig 3).
• Tighten the cover knob. The cover knob has a safety switch please ensure the knob is tightened or
the motor will not activate. (Fig. 5)
• NOTE: It is dangerous to use the machine without the hopper. (Fig. 6)
Assembly
5 6
Wheel Screw Spacer Wheel coverAxle bush
2
Foot A Foot B
Button
3
4
Hopper
Cover knob
