Safety
1-18 639782-1
FIG. 52:
18. Fuel filter - See the Lubrication & Maintenance
section.
Located on chassis frame near fuel filter.
FIG. 53:
19. Do not open or remove safety shields while engine
is running.
Located on the engine cover.
m
WARNING: Never reach into area’s with
rotating parts such as belts and pulley’s.
Serious personal injury, los of limbs,
could occur.
FIG. 54:
20. Engine oil filter - see the Lubrication &
Maintenance section.
Located on chassis frame near engine oil filter.
FIG. 55:
21. Warning - Burn Hazard - Avoidance: Stay clear. Do
not touch parts.
Safety sign is located near muffler on right side of
machine and near fan.
Avoid contact with hot surfaces. Exhaust piping
and engine components become hot during engine
operation and cool slowly after engine shutdown.
Any contact with hot surfaces cause severe burns.
FIG. 52
FIG. 53
FIG. 54
FIG. 55
