639782-1 1-19
Safety
FIG. 56:
22. 12 volt - see the Lubrication & Maintenance
section.
Located on chassis frame near main power key.
This machine is equipped with a 12 volt electrical
system.
m
WARNING: Never jump start a 12 volt
system with a 24 volt power supply.
Explosion hazard can occur causing
serious injury or death.
FIG. 57:
23. Ground connection - see the Lubrication &
Maintenance section.
Located on chassis frame behind engine.
FIG. 58:
24. Danger - Explosion Hazard - Disconnect Battery.
Safety sign is located on battery hold down
bracket.
Improper jumper cable connections can cause
explosion resulting in personal injury.
FIG. 56
FIG. 57
FIG. 58
