3 . INSTRUMENTS AND CONTROLS
3.13
Challenger MT500B EU
3
36. Diagnostics connector.
37. Cigar lighter.
3.7 - LEFT-HAND CONSOLE
(Fig. 17, Fig. 18)
38. Cigarette lighter type connector.
39. Electrical control for external rear-view mirrors
(optional).
40. Rear windscreen wiper.
41. Rear view mirror defrosting control (optional).
42. Passenger seat (optional).
43. Storage compartment.
44. Can carrier.
3.8 - SEAT
3.8.1 - Description (Fig. 19)
1. Weight adjustment
2. Height adjustment
3. Fore / aft adjustment
4. Backrest angle adjustment
5. Swivel adjustment
6. Adjustable backrest extension
7. Lumbar support adjustment
8. Fore / aft isolator control
9. Armrest angle adjustment
10. Seat pan angle adjustment
11. Seat depth adjustment
Fig. 16
Z2-415-05-03
35
37
36
Z2-613-05-03
Fig. 17
40
39
38
41
Z2-417-05-03
42
Fig. 18
44
43
X3A -2010- 10-0 4
Fig. 19
2
6
7
1
4
9
8
5
MT-0101103
3
1011
