24
Installation
STEP 10 Install the Door Control
PUSH BUTTON DOOR CONTROL
To prevent possible SERIOUS INJURY or DEATH from electrocution:
l Be sure power is NOT connected BEFORE installing door control.
l Connect door control ONLY to 12 VOLT low voltage wires.
To prevent possible SERIOUS INJURY or DEATH from a closing garage door:
l Install door control within sight of garage door, out of reach of small children at a minimum height of
5feet (1.5m) above floors, landings, steps or any other adjacent walking surface, and away from ALL
moving parts of door.
l NEVER permit children to operate or play with door control push buttons or remote control
transmitters.
l Activate door ONLY when it can be seen clearly, is properly adjusted, and there are no obstructions to
door travel.
l ALWAYS keep garage door in sight until completely closed. NEVER permit anyone to cross path of
closing garage door.
INTRODUCTION
Install the door control within sight of the door at a minimum height of 5 feet (1.5 m) above floors, landings,
steps or any other adjacent walking surface, where small children cannot reach, and away from the moving
parts of the door.
NOTE: Your product may look different than the illustrations.
Screw 6ABx1-1/2" (2)
HARDWARE
Drywall Anchors (2)
1. Strip 1/4" (6 mm) of insulation from one end of the wire and separate the wires.
2. Connect one wire to each of the two screws on the back of the door control. The wires can be connected
to either screw.
3. Mount the door control with the hardware provided.
To Next Page
