DOOR TYPES
1
A
B
C
2
1
10mm, 8mm,
4,5mm, 4mm
11mm, 13mm
4mm hex
head driver
TOOLS REQUIRED
A. One-piece door with horizontal track only
B. Sectional door with curved track
C
. One-piece door without track
To suit spring balanced doors up to 15.5m
2
HARDWARE PROVIDED
Chain Spreader Hardware:
(1) Flat washers (2)
(2) Hex screws (2)
(3) Chain spreader (1)
Installation Hardware:
(4) Large clevis pin (1)
(5) Carriage bolts (2)
(6) Wood screws (4)
(7) Clevis pins (medium) (2)
(8) Hex screws (4)
(9) Rope
(10) Handle
(11) Lock washers (6)
(12) Nuts (6)
(13) 4mm anchors (2)
(14) R-Clip (3)
(15) 8mm anchors (4)
(16) Sheet metal screw (4)
(17) Machine screw (2)
Vibration Isolator:
(a) Vibration isolator (2)
(b) Lock washers (2)
(c) Nuts (2)
4
9
8
5
6
7
13
12
11
15
10
N
O
T
I
C
E
16
14
2
1
3
a
b
c
17
2
3
