Chamberlain merlin MT5580P User Manual

4
1
2
3
4
7527SP1 (optional accessory)
2.75m Segmented pole pack
(separate carton)
3m Chain Pack and Joiner
Pole Adaptor Kit
6
5
7
10
9
11
8
(1) MT5580 opener
(2) Angled door arm
(3) Door mounting bracket
(4) Straight door arm
(5) Header bracket
(6) Stop collar and grub screw
(7) Pole kit adaptor
(8) Trolley assembly
(9) Idler
(10) Chain and joiner
POLE OPTIONS
(11) 7527SP1 2.75m segmented pole kit
NOT PICTURED
3m one piece pole
HARDWARE PROVIDED
4

Chamberlain merlin MT5580P Specifications

General

Brand	Chamberlain
Model	merlin MT5580P
Category	Garage Door Opener
Language	English
