Specifications
Rev 41513-20100224 English 19
Parts List
No Parts Number Description Qty
1 5P9 Control panel 1
2 DP03-00000000-2 Trigital Meter III 1
3 29.001 Switch 1
4 ST02FD-05502020 Receptacle L5-30R 1
5 GB818 M4×14 Screw M4x14 10
6 GB6177 M4 Nut M4 6
7 ST02FD-05502022 Receptacle L14-30R 1
8 ST02FD-05502023 Receptacle 5-20R 2
9 GB5783 M6×22 Bolt M6x22 1
10 GB97.1 6 Washerφ6 6
11 GB93 6 Spring washerφ6 6
12 GB6175 M6 Nut M6 2
13 GB5789 M6×12 Flange Bolt M6×12 15
14 ST02FD-05302001-L30 A.C 30A Breaker 2
15 ST01FD-05701001-1 Switch 1
16 LT02-00000000 Flood light(LED) 1
17 ST02FD-05302001-L20 A.C 20A Breaker 2
18 BG01-00000000 Rectifier 1
19 GB818 M5×14 Screw M5x14 1
20 GB97.1 5 Washer φ5 7
21 GB818 M5×38 Screw M5×38 3
22 ST05FD-05205011 Control panel cover 1
23 ST05FD-05215001 Build up 1
24 ST05FD-05215009 Conduit 1
25 ST05FD-05215003 Build up 1
26 ST190FDE-II-1000000-G 190-2-G style Engine 1
27 ST05FD-1151600 Cover 1
28 GB5789 M6×8 Flange Bolt M6×8 4
29 ST07FD-02011200 Rotor comp 1
30 GB96 10 Washer Φ10 1
31 GB7244 10 Spring washer Φ10 1
32 ST07FD-02011100 Stator assy 1
33 ST07FD-02010001 Flange bolt M10×1.25×280 1
34 ST07FD-02011001 Stator cover 1
35 ST07FD-02010002 Flange bolt M6×194 4
36 ST05FD-1152002 End cover 1
37 ST05FD-1152035 Brush assy 1
38 ST02FD-02100008 Brush assy cover board 1
39 ST07FD-02010100 AVR 1
40 ST02FD-02100010 Terminal 1
41 GB16674 M5×16 Flange Bolt M5×16 5
42 ST05FD-1152001 Generator end cover 1
43 GB16674 M5×12 Flange Bolt M5×12 4
44 GB93 5 Spring washer φ5 6
45 ST188FD-1732100 Muffler inter protector 1
46 GB5789 M8×35 Flange Bolt M8×35 1
47 ST188FD-1732001 Muffler inter protector gasket 2
48 GB5789 M8×20 Flange Bolt M8×20 1
49 ST190FD-II-1731000 Muffler 1
50 ST188FD-1732200-A Muffler outer protector 1
51 ST188FD-1180121 Spark arrester assy 1
52 ST188FD-1100010-88 Spark arrester cover 1
53 GB818 M5X14 Flange Bolt M5×14 2
54 ST188FD-1730100 Muffler gasket 1
55 GB16674 M8×25 Flange Bolt M8×25 2
56 ST188FD-1730001-G Ex pipe 1
57 ST188FD-1100001-G Muffler gasket 1
