Champion Model 44 - Page 113

Replacement Parts
105
1 329562 Screen, E44DR, R-L 1
2 329465 Screen, E44DR, R-L Rinse 1
3 329466 Screen, E44DR, L-R Rinse 1
4 329281 Screen, E44DR, L-R Rinse 1
5 329265 Manifold 1
6 180282 Nozzle 3
7 100156 Nut 1
8 108620 Gasket 1
9 112022 Nozzle 3
10 113795 Plug 1
11 329167 Manifold, Auxiliary Rinse 1
12 100156 Locknut 1
13 102102 Tubing 1
14 114021 Hose x 2-3/4" x 1" OD 1
15 105993 Clamp 6
16 206501 Tube, discharge L-R 1
--- 206503 Tube, discharge R-L 1
17 114020 Hose, 1-1/8" OD x 2-3/4" 1
18 329276 Bracket, Pump 1
19 0502692 Recycle Pump (Parts breakdown on next page) 1
20 110454 Nipple, Toe 1
21 102444 Elbow, street 90º 1
22 601814 Upper piping assy E44DR, Auxiliary 1
23 110454 Nipple, Toe 1
 24 111443 Switch,oat  1
25 113996 Heating Element 1
26 100589 Union, 1-1/2 1
27 415960 Piping Assy, drain 1
28 329467 Bracket, DR drain valve 1
29 0306618 Drain Valve 1
30 601707 Manifold, E44DR 1
31 331017 Basket, scrap 1
32 201241 Bushing, Face reducing 1
33 100537 Cross, Tee 1
34 113622 Gauge, Temperature 1
35 109069 Thermostat, control 1
 36 113604 Thermostat,xedHighlimit  1
37 322892 Cover, box 1
38 100007 Screw, 10-32 x 3/8 Truss Hd 1
39 100443 Nipple, close, 1-1/2 1
40 100036 Tee, 1-1/2" 1
41 100595 Bushing, reducer 1
E-44DR Dual Rinse Assembly •
