Champion Model 44 - Page 45

Replacement Parts
37
1 328974 Panel Assy., 44 Front Perimeter 1
2 327889 Panel, 25” Side Perimeter (Load, L-R, No PreWash) 1
3 327889 Panel, 25” Side Perimeter (Unload, L-R No Booster) 1
 4 329926 Bafe  1
5 327857 Door 1
--- 111026 Magnet, Door (Not Shown) 1
--- 113719 Switch, Reed Aleph (Not Shown) 1
6 108966 Door Handle 1
7 113691 Guide, U-channel Door 2
8 113486 Screw, 8-32 x 5/8 Flat Head SST 12
9 108250 Rod, Curtain 5/16 x 24-5/8 3
10 113720 Curtain 24 x 20-1/4 4 Ply (Load and Unload) 2
--- 109723 Curtain 24 x 6 -1/4 (Not shown) 1
11 100007 Screw 1/4-20 x 1/2 Truss Head SST 6
12 100734 Bolt 1/4-20 x 1/2 SST 3
Single Tank Doors & Panels •
