Champion Model 44 - Page 49

Replacement Parts
41
1 0509199 Drive Motor Switch 1
2 327918 Bracket, Motor Switch Mounting 1
3 103166 Sheave AK 39 5/8 Bore (44) 1
3 113893 Sheave AK 51 5/8 Bore (64) 1
4 327916 Plate, Drive Motor Mounting 1
5 327920 Plate, 44 Motor Assy Mounting 1
5 327917 Plate, 64 Motor Assy Mounting 1
6 327919 Bracket, Motor Spring Mounting 1
7 100154 Hex Nut Plain 5/16-18 SST 2
8 102376 Washer, Flat 5/16 x 3/4 x .06 SST 4
9 113702 Spring 0.6OD x 0.095 Wire x 1.5 Lg 1
10 113704 Screw, 5/16 x 3-1/2 Hex Head SST 1
11 113700 Bushing 3/8 x 3/4 x 1/16 Thrust Bronze 3
12 113703 Bushing, 3/4 x 7/8 x 3/8 x 1-1/8 Flg 1
13 113701 Bushing 1/4 x 3/8 x 1/2 x 1/16 Flg Bronze 1
14 113732 Motor, Gear 1/6HP 3PH 1
14 113679 Motor, Gear 1/6HP 1PH 1
15 100734 Bolt 1/4-20 x 1/2 Hex Head SST 2
--- 106482 Washer Lock 1/4 Split 2
16 100736 Bolt 1/4-20 x 3/4 Hex Head 3
--- 106482 Washer Lock 1/4 Split 3
17 100734 Bolt 1/4-20 x 1/2 Hex Head SST 2
--- 106482 Washer Lock 1/4 Split 2
Drive Motor Assembly •
