Replacement Parts
43
1 202381 Roller Crosshead 1
2 100868 Roller Stud Crosshead 1
3 107089 Nut Jam 1/2-13 1
4 206300 Crank, Rack Arm 1
5 206301 Shaft 5/8 Diameter 8-3/8 LG 1
6 206302 Housing, Bearing/Seal 1
7 102244 Seal 5/8” 1
8 206303 Gasket/Bearing Seal 1
9 100382 Bearing Jaf #EK104-10 1
10 100007 Screw, 10-32 x 3/8 Truss Head 1
11 104925 Washer 1/4 x 1 x 16 Gauge 1
12 103180 Wiper Ring 1
13 104916 Key 3/16 x 3/16 x 3/4 SST 1
14 100794 V-belt 4L 310 1
15 113892 Sheave AK 59-5/8 Bore 1
16 327924 Bracket, 44 Drive Bearing Mounting 1
17 113860 Bearing, Sealed 5/8 Bore 1
18 104923 Screw 1/4-20 x 3/8 Round Head 4
19 100153 Bolt 3/8-16 x 1 Hex Head 4
--- 104618 Washer 3/8 x 7/8 x 1/16 SST 4
--- 109010 Nut Grip 3/8 w/Nylon Insert 4
20 100739 Bolt 5/16-18 x 3/4 Hex Head SST 2
--- 100154 Nut Plain 5/16-18 2
--- 106013 Washer Lock 5/16 Split 2
--- 109009 Nut Grip 5/16 w/Nylon Insert 2
Drive Assembly •
To Next Page
