Replacement Parts
45
1 113719 Switch, Reed Aleph 1
2 328045 Switch, PW Idle 1
3 111026 Magnet, SS 1
4 100764 Screw, 6-32 x 1/2 Round Head SST 2
5 108954 Nut, Grip 6-32 Hex Head W/Nylon Insert 2
6 106482 Washer Lock 1/4 Split 2
7 327833 Pin Idle Pump Switch 1
8 100736 Screw, 1/4-20 x 3/4 Hex Head 2
9 328041 Track, 22” PW Rear 1
10 328043 Cradle, 22” PW 1
11 204513 Pawl, NG Cradle 4
12 206345 Bushing, Rack Cradle Pawl 4
13 113692 Screw, 3/8 x .875 x 5/15-18 4
14 328450 Bracket, Cradle bridge Single Tank, 22" PW 2
14 328613 Bracket, Cradle Bridge Two Tank 36" PW 2
15 206343 Bearing, Rack Cradle Slide 4
16 327955 Track, 22” PW Front 1
17 100736 Bolt 1/4-20 x 3/4 Hex Head SST
18 112318 Washer 4
--- 100141 Nut, Grip 1/4-20 4
19 100142 Nut, Grip 5/16-18 1
20 100736 Bolt 1/4-20 x 3/4 Hex Head SST 2
--- 106482 Washer Lock 1/4-20 Split 2
Prewash Track & Cradle Assembly •
To Next Page
