Outdoor Use, Mast Mounting:
1. Assemble the metal mount (Fig. a) using the two (10
mm) round head screws provided.
Figure a
2. Attach the metal mount to the antenna unit using the
two 0.6” (15 mm) screws provided (Fig. 6).
Figure 6
3. Using the instructions provided with the mast and/or
mast mount, install the mast on the house, preferably
on the side of the house facing the TV station
transmitters.
