MDS-6A
INSTALLATION MANUAL
© Channel Plus, Inc 2004 • All rights reserved. 4/04 Page 7
1.3 - MDS-6A F
RONT PANEL
ADJUSTMENTS
Music-On-Hold Output Gain Adjustment
As shown on page 6, this potentiometer adjusts the gain of the Music-On-Hold signal
(Source #1) going to the Music-On-Hold input of a phone system or other communication
device.
Page/Doorbell Input Gain Adjustment
Adjusts the input level of the Page and Doorbell signal.
Zone Status LED Indicators
SOLID Indicates the zone is on.
Power LED
Indicates the MDS-6A is powered up.
IR Activity Indicator LED
WINKING Indicates that IR data is being received from a keypad or IR Receiver in a
zone.
