Channel Plus MDS-6A User Manual

MDS-6A
INSTALLATION MANUAL
Page 8 © Channel Plus, Inc. 2004 • All rights reserved. 4/04
REPLACE FUSE WITH SAME
TYPE AND RATING ONLY
T4AL TYPE FUSE
POWER
120VAC
60 Hz
440 W
FUSE
MODEL: MDS-6A
MUSIC DISTRIBUTION SYSTEM
WARNING: DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICE TO CHANNEL PLUS
SERVICE TECHNICIAN.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
HOME SYSTEMS WITH AUDIO AND/OR VIDEO CONTROL CAPABILITIES.
ETL LISTED PRODUCT CONFORMS TO UL STD 6500 2ND EDITION
CERTIFIED TO CAN/CSA E60065-00
9700721
C
US
CM
I
N
T
E
R
T
K
E
L
I
S
T
E
D
MCS
KEYPADS
IR
EMITTERS
Sources x 6
In-Wall & In-Ceiling Speakers
ZONES 1-6
SYSTEM OVERVIEW
2.1- SYSTEM OVERVIEW
Figure 2
SECTION 2 - CONNECTIONS AND SETTINGS
BLUE
WHITE/BLUE
ORANGE
WHITE/ORANGE
GREEN
WHITE/GREEN
BROWN
WHITE/BROWN
1
2
3
4
5
6
7
8
PIN # COLOR CODE
FRONT
CABLE
Standard Channel Plus RJ-45 Pin-Out
TAB
Figure 4
Blue (N/C)
White/Blue (IR)
Orange (Clone Data)
White/Orange (RS485+)
Green (RS485-)
White/Green (+12VDC)
Brown (Ground)
White/Brown (N/C)
MCS ControllerMDS-6A
(N/C)Blue
(IR) White/Blue
(Clone Data) Orange
(RS485+) White/Orange
(RS485-)Green
(+12VDC) White/Green
(Ground)Brown
(N/C)White/Brown
RJ45
Jack
Pin #
1
2
3
4
5
6
7
8
MDS-6A/MCS Controller RJ45 PIN-OUT
The MDS-6A RJ-45 keypad jacks and all MCS Controlle
r
RJ-45 jacks have the exact same pin-out.
Figure 3
