ASSEMBLY INSTRUCTIONS
The Chapin 8700 Chest Spreader is preassembled at our factory, leaving only the crank
handle for you to attach. To attach, remove nut, slide handle through plastic base and fully
tighten the nut. Insert handle into gear and turn clockwise to tighten. Use a 14mm wrench
to snug the nut against the gear. (Fig. A)
FIGURE A
1E
WARNING
IMPROPER USE OR FAILURE TO FOLLOW INSTRUCTIONS CAN RESULT IN
EXPLOSIVE FAILURE CAUSING SERIOUS EYE OR OTHER INJURY.
Chapin Chest Spreader Operator’s Manual - English
