30
∆ιάγραµµα σύνδεσης
βαλβίδας αερίου και
ηλεκτρικού αναφλεκτήρα.
Connection diagram of gas
valve and electric igniter
0404_2601
ΗΛΕΚΤΡΟ∆ΙΟ ΑΝΑΦΛΕΞΗΣ
ΣΥΝ∆ΕΤΗΡΑΣ ∆ΙΑΚΟΠΤΗΣ ΑΝΑΦΛΕΞΗΣ
ΒΑΛΒΙ∆Α ΑΕΡΙΟΥ HONEYWELL
HONEYWELL GAS VALVE LIGHTER
CONNECTOR
LIGHTER ELECTRODE
