Char-Broil Performance T-47D User Manual

3
A
Lower back panel
1/4-20x1/2" screw
15
Grill head
Regulator hose
Vertical flange
Place lower back panel between side panels at rear of bottom shelf. Make sure the slots are positioned as shown
(A). Secure lower back panel to side panels using two 1/4-20x1/2” screws on each side.
The vertical flange should be on left
side when the lower back panel is
properly installed
4
This step requires two people to lift
and position grill head onto cart.
Carefully lower the grill head onto the
cart, aligning slots at bottom of grill head
with posts on cart side panels. Make
sure the regulator hose is hanging
outside the cart. Grill head must face
open side of cart.
