- 4 -
PRE-ASSEMBLY
1. Attach four suction cup feet to the base and tighten the suction cup bolts.
2. a. Loosen and remove the two handle bolts from the cutter base.
b. Position the handle correctly, the curve of the handle
should face inwards.
c. Slide both handle bolts through the handle holes,
attach the two handle nuts and tighten.
ASSEMBLING THE CUTTING PLATE:
1. Loosen and remove the three wing nuts on front of blade frame housing.
2. Place the cutting plate on the unit with the cutting side facing the pusher,
re-tighten the wing nuts on the front of the unit.
3. Make sure the push plate fits into the cutting plate properly.
ASSEMBLING THE PUSH PLATE:
1. Loosen and remove the 2 push plate screws.
2. Place the push plate properly so the screw holes align vertically on the
push base.
3. Tighten the push plate screws.
ASSEMBLY INSTRUCTIONS
BEFORE FIRST USE
Take contents out of retail box and dispose of waste properly.
Thoroughly wash parts with warm soapy water and dry completely.
