DECK CONTROLS
86037810 CHARIOT® VACUUM 12/16/06
3-9
Brush Lift Lever
Brush Lift Lever
Raises and lowers the brush deck and turns the vacuum motor on and off.
To lower brush deck and start vacuum motor and brushes, lift the lever from its raised position.
To raise brush deck and stop vacuum motor and brushes, lift the lever from its lowered position.
Side brush on deluxe model only.
Deluxe Model
The brush lift lever also raises and lowers the side broom.
