TECHNICAL SPECIFICATIONS
86037810 CHARIOT® VACUUM 01/03/07
3-1
ITEM DIMENSION/CAPACITY
Nominal Power (Basic) 1548 W
Nominal Power (Deluxe) 1692 W
Rated Voltage 36 Volts DC
Rated Amperage (Basic) 43 amps
Rated Amperage (Deluxe) 47 amps
Batteries 3 X12 Volt 195-215 AH @ 20 hr. rate
Battery Compartment Dimensions
21 in. x 16 in. x 17 in. tall
(533mm x 406mm x 432mm)
Propelling Motor .75 HP (560 W)
Brush Motor .75 HP (560 W)
Bag Capacity 2150 in³ (35 L)
Brush Two 28 in. (71 cm) by 4 in. (10 cm) diameter
Brush Speed 1725 RPM
Vacuum Motor(s) .75 HP (560 W)
Maximum flow rate of vacuum motor 200 cfm (95liters per second)
Maximum suction of vacuum motor 13.8 inches of water ( 3.43 kPa)
Mass (GVW) (Basic) 1055 lbs (478 kg)
Mass (GWB) (Deluxe) 1065 lbs (483 kg)
Weight Empty Without Batteries (Basic) 495 lbs (225 kg)
Weight Empty Without Batteries (Deluxe) 505 lbs (229 kg)
Tires 10 in. (254mm) Solid Gray non-marking
Foundation Pressure (Basic) 77 psi (530 kPa)
Foundation Pressure (Deluxe) 79 psi (544 kPa)
Maximum Speed 3.5 miles/hour (5.6 Km/hour)
Theoretical Coverage - Basic 28,600 ft²/hr (2,660 M²/hour)
Theoretical Coverage – Deluxe 35,200 ft²/hr (3,270 M²/hour)
Frame Construction Powder coated steel
Brake
Electrical parking brake, sets automatically
whenever operator steps off platform or
engages emergency stop.
Minimum Aisle U-Turn Width 56 in. (1425 mm)
Maximum Rated Climb And Descent Angle 9.5 degrees
