MAINTENANCE- CIRCUIT PROTECTION
86037810 CHARIOT® VACUUM 12/16/06
4-10
CIRCUIT BREAKERS
CIRCUIT BREAKERS
Circuit breakers interrupt the flow of power in the
event of an electrical overload. When a circuit
breaker is tripped, reset it by pressing the
exposed button. If a circuit breaker continues to
trip, the cause of the electrical overload should
be found and corrected.
30 Amp. Protects the brush motor.
30 Amp. Protects the propel
motor.
3 Amp. Protects the machine
controls.
3 Amp. Protects the side
broom.
30 Amp. Protects the vacuum
motor.
