Charmate CBQ2003 - Parts and Accessories

2
10.Placecookinggrid(D)insideofupperbody 
 (G)ongridsupport(E).
11.Mountdomehandle(A)todome(B)withone
 bolt(B4).
Note:Charcoalbowl(K)sitsontopoftheleg
brackets(J)withcharcoalgrid(N)inthisbowl.
Waterbowl(H)sitsontopofgridsupportsin
lowerbody(I)andonecookinggrid(D)sitson
topwaterbowl.Secondcookinggrid(D)sitson
gridsupportsinupperbody(G)
Parts & Accessories
• BeforeSmoker&Grillcanbeleftunattended,
remainingcoalsandashesmustberemoved
fromSmoker&Grill.Usecautiontoprotect
yourselfandproperty.Placeremaining
coalsandashesinanon-combustiblemetal
containerandcompletelysaturatewithwater.
Allowcoalsandwatertoremaininmetal
container24hourspriortodisposing.
• Extinguishedcoalsandashesshouldbe
placedasafedistancefromallstructuresand
combustiblematerials.
• Withagardenhose,completelywetthe
surfacebeneathandaroundSmokerto
extinguishanyashes,coalsoremberswhich
mayhavefallenduringthecookingorcleaning
process.
• StoretheSmoker&Grilloutofreachof
children,indoorsinadrysecurelocationwhen
notinuse.
• DonotattempttoserviceSmoker&Grill
otherthannormalmaintenanceasexplained
in“After-UseSafetyandProperCare&
Maintenance”sectionsofthismanual.
• Properlydisposeofallpackagingmaterial.
 Usecautionandcommonsensewhen 
 usingyourSmoker&Grill.
 Failuretoadheretothesafetywarnings 
 andguidelinesinthismanualcouldresult
 inbodilyinjuryand/orpropertydamage.
Pleasekeepthismanualforfuture 
 reference.
Assembly Instructions
1.AttachdoortoLowerBodyusingeightbolts 
 (B1)andeightnuts(N1).
2. Attacheachleg(J)tothelowerbody(I)with
 tworoundheadbolts(B2)andnuts(N2).
3. Attachthe3gridsupports(E)totheinsideof
 thelowerbody(I)usingoneroundheadbolt
 (B2)andnut(N2)persupport.
4. AttachairventtoDomeusingbolt(B3)and 
 nut(N3).
5. Placecharcoalbowl(K)insidelowerbody(I)
 ontopoflegs.
6. Placecharcoalgrid(N)intocharcoalbowl(K)
7. Placewaterbowl(H)andcookinggrid(D)on
 gridsupports(E)inlowerbody(I).
8. Attachtwosidehandles(F)ontheoutsideof
 upperbody(G)usingonehexheadbolt(B4)
 perhandle.Tightenwithscrewdriverfrom 
 insidethebody.Note:Donotturnhandleto 
 tighten.
9. Attachthe3gridsupports(E)totheinside 
 oftheupperbody(G)usingoneroundhead 
 bolt(B2)andnut(N2)persupport.
PartsList Description Quantity
A DomeHandle 1
B Dome 1
C Thermometer 1
D CookingGrid 2
E GridSupport 6
F SideHandle 2
G UpperBody 1
H WaterBowl 1
I LowerBody 1
J Leg 3
K CharcoalBowl 1
L Door 1
M AirVent 1
N CharcoalGrid 1
Hardware Description Quantity
B1 #M3*6BOLT 8PCS
N1 #M3NUT 8PCS
B2 #M6*12BOLT 12PC
N2 #M6NUT 12PC
B3 #M5*10BOLT 1PC
N3 #M5NUT 1PC
B4 #M6*25BOLT 3PCS
A.
C.
D.
F.
G.
D.
H.
K.
I.
J.
M.
B.
E.
N.
E.
L.
