22
BATTERY (12 volts)
Interventions
1) Removal
• disconnect the post - (black cable)
• disconnect the post + (red cable)
• unscrew the retainer
• take the battery
2) Replace in place
• target the battery in its place
• fix it
• connect the pole + (red cable)
• connect the pole - (black cable)
Long stop (winter)
During cold periods we recommend that
you disconnect the battery (disconnect
from the -)
WARNING
If you wish to recharge your battery, it
is imperative to disassemble it from the
car and load it into a ventilated area.
It should be handled with great
care as it contains highly toxic and
corrosive acid. In case of contact
with skin or clothing, rinse with clean
water immediately. Be careful not
to short-circuit the terminals with
a metal object. Before working on
electronic circuits, disconnect the
cable from the negative terminal. We
recommend that you perform this
procedure at your CHATENET dealer.
FRONT
Low / medium beam H7 - 12V / 55 W
Daylight LED
Blinkers LED
Fog light H11 - 12V / 55 W
REARS
Blinkers 12 V / 21 W orange
Daylight LED
Stop LED
Reversing lights 12 V / 21 W white
Fog light 21 V / 21 W white
Plate light 12 V / 5 W
INDOOR
Roof light 12 V / 5 W
Trunk light 12 V / 5 W
LIGHTS
