2. INTRODUCTION
Features
Universal DMX-512 optical splitter
One input to four outputs (3-pin and 5-pin)
Additional thru output (3-pin and 5-pin)
Electrical isolation between input and output
1-space (1U) rack mount
Product Overview
Ears for
rackmount
Power input
cable
DMX In
3 & 5-pin
DMX
signal
indicator
Link out/
DMX through
Power
indicator
13mm
mounting/clamp
location
Fuse
