Chauvet LEDRain 56C - User Manual

Questions and Answers

P
Pamela HicksJul 31, 2025
What to do if my Chauvet Flood Light fixture is not responding to DMX?
- K
  kevin38Jul 31, 2025
  If your Chauvet Flood Light fixture isn't responding to DMX, there are several possible causes: * **Wrong DMX addressing:** Check the control panel and unit addressing. * **Damaged DMX cables:** Inspect the DMX cables for damage. * **Wrong polarity settings:** Verify the polarity switch settings on the controller. * **Loose DMX cables:** Ensure all cable connections are secure. * **Faulty DMX interface:** Replace the DMX input. * **Faulty Main PCB:** Replace the Main PCB.
B
Brittany RodriguezAug 7, 2025
How to troubleshoot a Chauvet Flood Light that does not power up?
- T
  Tim BradleyAug 7, 2025
  If your Chauvet Flood Light doesn't power up, the issue might stem from: * **No power:** Ensure the power outlet has power. * **Loose power cord:** Check the power cord to make sure it is securely connected.
D
Douglas HillAug 14, 2025
Why does my Chauvet LEDRain 56C Flood Light breaker/fuse keep blowing?
- A
  Amy TaylorAug 14, 2025
  If the breaker or fuse keeps blowing in your Chauvet Flood Light, it could be due to: * **Excessive circuit load:** Examine the total load placed on the electrical circuit. * **Short circuit:** Inspect the electrical wiring (internal and/or external) for a short circuit.
J
Jeremy AdkinsAug 22, 2025
What causes loss of signal in Chauvet Flood Light and how to fix it?
- J
  josephwhiteAug 22, 2025
  A loss of signal in your Chauvet Flood Light could be caused by several factors. Here's how to address them: * **Non DMX cables:** Ensure you are only using DMX compatible cables. * **Bouncing signals:** Install a terminator. * **Long cable/Low level signal:** Install an amplifier right after the fixture with a strong signal. * **Too many fixtures:** Install an optically coupled DMX splitter after unit #32. * **Interference from AC wires:** Keep DMX cables separated from power cables or black lights.

Summary

Getting Started with LEDrain 56 C

Essential Safety Instructions

Critical safety guidelines for installation, operation, and maintenance to prevent hazards.

LEDrain 56 C Setup and Installation

AC Power Connection and Safety

Details on connecting AC power, voltage compatibility, and grounding.

Power Linking Multiple Fixtures

Mounting and Rigging Guidelines

Operating the LEDrain 56 C

DMX Addressing and Operation

Setting the DMX start address and operating the fixture via DMX controller.

Fixture DMX Personalities

Explains the 7-channel and 3-channel DMX modes for different control schemes.

Master;Slave and Standalone Modes

Operating modes like Master/Slave, Automatic, Sound-Active, and Static Colors.

Strobe Speed Control

Fixture Linking for Control

DMX Channel Functionality

Detailed mapping of DMX channels to functions like Red, Green, Blue, Dimmer, and Macros.

Troubleshooting and Procedures

General Troubleshooting Guide

A guide to diagnosing and resolving typical problems encountered with the fixture.

Technical Specifications Details

Power Specifications

Chauvet LEDRain 56C Specifications

General

auto-ranging power supply	100~240 VAC, 50/60 Hz
power consumption @ 120 VAC, 60 Hz	8 W (0.2 A) max, 0.2 A inrush
power consumption @ 230 VAC, 50 Hz	5 W (0.1 A) max, 0.2 A inrush
power output	37 units max
fuse	F 2 A, 250 V
LED	108 x 10 mm (36 red, 36 green, 36 blue) 100, 000 hrs
luminance @ 1 m	1, 390 lux
beam angle	20°
field angle	32°
maximum ambient temperature	104° F (40° C)
