Check Point 4000 Appliances Getting Started Guide | 39
Chapter 4
Check Point 4000 Appliances
Hardware
In This Chapter
Front Panel Components 39
Rear Panel Components 44
Replacing and Upgrading Components 45
Front Panel Components
This section describes the features and components located on the appliance front panel.
Check Point 4200 Front Panel
Item
Description
1
Expansion line card slot
2
Built in Ethernet ports (ETH1 - ETH3)
3
Management configuration port - Ethernet connection to a remote management
workstation
