Checkpoint 1250E Series - Figure 5: Name & Function Diagram

1250E & 1500E Electric Pump
Operating Manual
CP/MAN-PRD-1215E REV. 02 EFF. DATE: 12/15/12 Page 13 of 13
13. FIGURE 5: NAME & FUNCTION DIAGRAM
ID
NAME/FUNCTION
1
ELECTRIC MOTOR
2
PLUNGER-TYPE CHEMICAL HEAD
3
PACKING ADJUSTMENT NUT
4
BLEED SCREW
5
SUCTION CHECK VALVE
6
DISCHARGE CHECK VALVE
7
INSPECTION/CLEANOUT PLUG
8
STROKE LENGTH ADJUSTER
9
STROKE LENGTH ADJUSTMENT GAUGE
10
GEAR OIL LEVEL DIPSTICK/FILL PLUG
