Emergency Procedures
129
Turn signal, back-up,
rear fog lamps bulb
12V 21W
License plate, position,
turn signal and
high-mount stop lamps
bulb
12V 5W
Stop/position lamp
bulb
12V 21W/ 5W
Front fog lamp bulb
12V 55W
After the headlamp bulb is
replaced every time,
calibrate the headlamp. The
Chery’s special service station can
offer you the service.
Headlamp unit (high
beam/low
beam/position/turn signal
lamps inclusive)
Any bulb above can be removed only
after the headlamp unit is removed.
1. Open the engine compartment
bonnet.
2. Unscrew the protecting hoods
from the low beam and the high
beam bulb in the anticlockwise
direction according to the
position as shown in the diagram.
Remove the harness connector
from the bulb, press downward
the clip of bulb holder by hand so
as to make the clip get through
the location groove and split
towards the both sides, take out
the bulb, and pay more attention
to the location mark of the bulb.
3. CAUTIONDO NOT touch the
surface of new bulb by hand in order to
avoid it affects the brightness of the
