Vehicle Care 213
A fuse puller is in the underhood
compartment fuse block.
The vehicle may not be equipped with all of
the fuses, relays, and features shown.
Fuses Usage
1 –
2 Power window rear
3 –
4
Rechargeable energy
storage system 1
5 –
7 Left high beam headlamp
8 Right high beam headlamp
9 Left low beam headlamp
10 Right low beam headlamp
11 Horn
12 –
13 Front wiper motor driver
14 Liftgate
15 Front wiper motor co-driver
16
Electronic brake control
module supply electronics
Fuses Usage
17 Rear wiper
18 Liftgate
19 Seat module front
20 Washer
22 Linear power module
23
Electronic brake control
module supply motor
24 Seat module rear
26
Transmission range control
module
27 Aeroshutter
28 Auxiliary oil pump
29
Electric brake boost motor
source
30 Front power windows
31
In-panel bussed electrical
center
32 Rear window defogger
33
Heated exterior rearview
mirror
34
Pedestrian friendly alert
function
Fuses Usage
35 –
36 –
37 Current sensor
38 Rain sensor
39 –
40 Electric brake boost (ECU)
41
Power line communication
module
42 Infant only supression
43 Window switch
44
Rechargeable energy
storage system
45
Vehicle integration control
module
46
Integrated chassis control
module
47 –
48
Integrated chassis control
module
49 Interior rearview mirror
50 –
