168 Vehicle maintenance
Jack supporting point
Front axle
As shown in the above figure, the jack
is lifted on the skirt of the side wall,
and the corresponding part is
provided with a triangular mark for you
to find.
The lifting point is also the lifting point
of the lift, and the tray of the lift is
aligned with the triangular mark. The
lifting point has been specially
strengthened, so be sure to aim.
Replacement of tires:
1. Remove tools, jacks and spare tires.
Check that the diagonal tires have
been secured with blocks or stones.
2. Use a socket wrench to loosen the
wheel nuts, one each for each turn.
3. Place the jack directly below the
lift point closest to the tire to be
replaced.
Do not remove any nuts until
you lift the wheels off the
ground.
Do not attempt to lift the
vehicle until the jack enters
the proper position. Secure
the jack between the vehicle
and the ground.
